Dahua DH-XVR1B08 User Manual

Local Configurations 75
After you have configured the video recording settings, on the Record interface, click Step 1
Next.
The SNAPSHOT interface is displayed. See Figure 5-35.
Figure 5-35
Configure the snapshot settings parameters. See Table 5-10. Step 2
Parameter
Description
Channel
In the Channel list, select a channel to take a snapshot.
Event type
Select the check box of the event type which includes General, MD,
Alarm, MD&Alarm, Intel, and POS.
Period
Define a period during which the configured snapshot setting is active.
For details about defining a period, see "5.1.4.9 Configuring Recorded
Video Storage Schedule."
Copy
Click Copy to copy the settings to other channels.
Table 5-10
Click Finished. Step 3
A pop-up message is displayed.
Click OK. Step 4
The live view screen is displayed. The setting with startup wizard is completed. You can
start using the Device.
(Optional) After the setting with startup wizard is completed, if the connected HDMI Step 5
display resolution is inconsistent with default resolution (1280*1024), a dialog box will
pop up. See Figure 5-36. Choose to switch the resolution or not.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
