User’s Manual
6
ATE
Category
Reporting
Time
Protocols Communication Devices
Communication
Device to be Used
- - - PSTN 2G/3G IP -
SP5 90 s Encrypted √ √
Only one of the two
check marked
communication
devices
DP1 25 h Standard √ √ √
Only two of the
three check marked
communication
devices
DP2 30 min Standard √ √ √
Only two of the
three check marked
communication
devices
DP3 3 min Encrypted √ √
The two check
marked
communication
devices
DP4 90 s Encrypted √ √
The two check
marked
communication
devices
ATE: Alarm transmission equipment.
SPx (Single Path): A value that indicates the performance level achieved by a single
communication device, according to the EN 50136–1 standard.
DPx (Double Path): A value that indicates the performance level achieved by a combination of
two communication devices, according to the EN 50136–1 standard.
Reporting time: The reporting time is prescribed based on the standard of each level of
performance. Reporting time is the maximum time available to report when an alarm
transmission device fails. Alarm transmission devices meet this requirement by regularly
reporting their status through a specific symbolic test function.
Protocols: Indicates the security level of the protocols to be used for the notification of failures.
Standard protocols and voice protocols are encrypted. High security protocols are encrypted with
an AES 128 bit or AES 256 bit encryption key.
Communication devices: Implemented communication devices.
Communication devices to be used: Indicates the number of and which communication devices
are to be used based on the ATE category.
Table 1-3 Technical specification
Technical Specification Description
ACE Classification Type A
Environmental Class II
Installation Wall mount
Table 1-4 Terms and definitions
Term Description
Area 8 areas that can be armed.
