Dahua DHI-ARC3008C - In and Zones

137 pages

To Next Page

To Previous Page

User’s Manual

Figure 6-5 Secure the antenna patch cord

Step 6 Connect the 4G module to the 4G port on the main board with the provided wire.

Step 7 Inset the SIM card into the 4G module.
