Note: Favorites is only available on HCVR74XXL, HCVR78XXS, HCVR5424/32L (-S2),
HCVR5824/32S (-S2), DVR7X series and used to save the current layout of the splits.
You need to go to the Main menu->Setting->System->General to enable navigation bar
function first and then set the favorites.
The navigation bar is shown as below. See Figure 4-7.
Figure 4-8
Click , system pops up the following interface. See Figure 4-8. Click one item, you can view
saved favorite channel split mode and channel number. You can add the favorites by clicking
the “Add to Favorites” and delete them by clicking “Edit Favorites”. Please note, right now the
favorite scheme names after the window split mode.
4.6 How to set mask
Figure 4-9
In the main button, from Main menu->camera->encode->overlay button, you can see an
interface is shown in the following Figure 4-9.
Cover area: Here is for you to cover area section. You can drag you mouse to set
proper section size. In one channel video, system max supports 4 zones in one channel.
Preview/monitor: The cover area has two types. Preview and Monitor. Preview
means the privacy mask zone cannot be viewed by user when system is in preview status.
Monitor means the privacy mask zone cannot be view by the user when system is in
monitor status.
4.7 How to make the digital zoom
