98
In Preset box, select a preset (the blue font, , for example, means the Step 2
preset has already enabled Call Detection).
The whole surveillance image is set as the call detection area by default (as indicated by the Step 3
yellow box). If you want to form a specific area, a pentagon, for example, click Clear to clear
the yellow box. Then click Draw Rule and draw a polygon to form the area you want to
monitor.
If you want to define a specific period (4:00–23:59, for example) for the call detection to Step 4
work (this means perhaps you don’t need to pay attention to the scene at 00:00–4:00), click
Setting next to Period to define every day in a week.
If you want to set the lasting time of calling behavior beyond which the linked action such Step 5
as Relay-out, Send Email and Record will be triggered, fill in a value from 1 to 600 in the
Duration box (the default value is 5). For example, if you are at a gas station and pay much
attention to calling behavior, set Duration to 2 or a less value.
If you want to set the sensitivity, drag the sliding block next to Sensitivity. The larger the Step 6
value is, the more sensitive the call detection will be.
Select Enable to enable the preset’s call detection. Step 7
For linked action settings, see "4.4.10 Configure Linked Measures." Step 8
Click Save. Step 9
4.4.3.3 View Web Interface Alarm Records
After finishing settings in "4.4.3.1 Configure Smart Plan" and "4.4.3.2 Configure Call Detection", s el ect
Alarm tab and select IVS in Alarm Type to enable alarm notifications on the web interface.
Then view calling behavior records on the Alarm tab when an alarm is triggered.
4.4.4 Smoking Detection
4.4.4.1 Configure Smart Plan
Select a preset for which you can enable the Smoking Detection first. Then you can configure
detailed settings.
Go to the Live interface and select Preset in PTZ function box. Then select a preset number and
click to examine whether or not it’s the scene where you want to monitor
calling behavior. See Figure 4-49. If not, go to Setting > PTZ > Function > Preset to add a new
preset.
PTZ function Figure 4-50
Go to Setting > Smart Thermal > Smart Plan. The Smart Plan interface is displayed. Step 10
