128
4.6.2 Configuring Global Setup
You can enable Temperature Switch, Isotherm and Color Code.
Temperature Switch: A switch with which you can enable or disable temperature testing rules.
Enable the Temperature Switch and the temperature testing rules you have set will be
displayed on surveillance images.
Isotherm: Used to highlight an object in images of high brightness. Isotherm is based on
median temperature, with highest temperature and lowest temperature as its range. The part of
an object whose temperature is higher than floor temperature will be represented in a bright
color and the part of an object whose temperature is lower than floor temperature will be
represented in a black/white color.
Color Code: Enable this function, and a color code is displayed on the right side of surveillance
images to show change of color between minimum temperature and maximum temperature.
Select Setting > Temperature > Global Setup. Step 1
The Global Setup interface is displayed. See Figure 4-72.
Global setup Figure 4-72
Configure the global setup parameters. See Table 4-42. Step 2
Table 4-42 Parameter description of global setup
Parameter Description
Temperature Switch Select the check box to enable this function.
Temperature Unit Includes °C and °F.
Relative Humidity Relative humidity of environment. Ranges from 0RH – 100 %RH.
Atmospheric
Temperature
Temperature of our environment. Ranges from -50 °C to 327.7 °C.
Target Radiation
Coefficient
Set Radiation coefficient of targets that are shot by this Camera. Ranges
from 0.5 – 1.
Target Distance
Distance from the camera to targets that are shot. Ranges from 0m –
10000m.
Target Reflection
Temperature
The temperature radiation of the objects around the target. It reflects to
the Camera through target surface to affect the test results.
