119
Snapshot
Select the Snapshot check box to take a snapshot when there is an alarm.
To view and set storage path of snapshots, see "4.1.2.5 Configuring Storage
Path".
To make the snapshot function take effect, you need to firstly enable
motion-detection snapshots. See "4.7.1.2 Configuring Snapshot" for detailed
operations.
Click Save. Step 4
4.5.4 Configuring Alarm
When there is an alarm from external Cameras, an alarm will be released and linked activities will be
executed.
Select Setting > Event > Alarm. Step 1
The Alarm interface is displayed. See Figure 4-63.
Alarm settings Figure 4-63
Select the Enable check box. Step 2
Configure Relay activation parameters. See Table 4-35. Step 3
Table 4-35 Alarm parameters
Parameters Description
Relay-in Select an external alarm Camera.
Period
Define a period during which the alarm settings are active.
1. Click Setting, and the period setting interface is displayed.
2. Configure period.
Method
1: Hold down and drag the left mouse button to select
working period you need.
Method 2: Select Setting > Event > Video Detection and click Setting
on the right side of Period. An interface is displayed. In this interface,
there are seven Settings altogether each of which corresponds to a
day in a week. Select a Setting you want and there are six periods
(period1-period6) below for you to pick up.
3. Click Save of working period.
Anti-dither Only one temperature alarm event is recorded within the time you have set.
Sensor type You can select from normally open (NO) and normally closed (NC).
