80
Multicast Figure 4-34
Select Enable and then enter IP address and port number. See Table 4-18. Step 2
Table 4-18 Multicast
Parameter Meaning
Description
The Multicast IP address of Main Stream/Sub Stream is 224.1.2.4 by default,
and the range is 224.0.0.0–239.255.255.255.
Port
See the multicast port of corresponding stream: Main Stream: 40000; Sub
Stream1: 40016; Sub Stream2: 40032, all the range is 1025–65500.
Click Save, and the login interface is displayed. The configuration finishes. Step 3
In the Live interface, set Protocol to Multicast, and then you can view the video image with
Multicast protocol.
4.2.10 Configuring Auto Registration
In the Auto Register interface, you can set an IP address to which the camera will report its location.
Select Setting > Network > Auto Register. Step 1
The Auto Register interface is displayed. See Figure 4-35.
Auto registration Figure 4-35
Select the Enable check box. Step 2
Set auto registration parameters. See Table 4-19. Step 3
Table 4-19 Auto registration parameter description
Parameter Description
IP Address IP address or domain name to which the camera transmits its location.
Port The port for auto registration.
Sub-Camera ID Your Camera ID given by the server.
Click Save. Step 4
4.2.11 Configuring 802.1X
802.1X can control the Camera’s access to LAN.
Select Setting > Network > 802.1x. Step 1
The 802.1x interface is displayed. See Figure 4-36.
