Dahua TPC-BF1241-B3F4-S2 User Manual

35
If you want to export or import presets, you have to obey the following steps.
Select Setting > PTZ > Preset Backup. Step 1
The Preset Backup interface is displayed.
Preset backup Figure 3-27
Export or import presets. Step 2
 Click Export to export presets for backup.
 Click Import to import presets you have already backed up
Playback 3.3
Playback of both videos and pictures is supported.
Functions of different Cameras might vary, and the actual product shall prevail.
Click the Playback tab, and the Playback interface is displayed. See Figure 3-28.
Playback Figure 3-28
3.3.1 Video Playback
3.3.1.1 Interface Layout
Select dav in the File Type list, and the video playback interface is displayed. See Figure 3-29. On the
Playback interface, there are seven function bars. See Table 3-8.
