81
802.1x Figure 4-36
Select the Enable check box. Step 2
Set 802.1x parameters. See Table 4-20. Step 3
Table 4-20 Parameters of 802.1x
Parameter Description
Authentication PEAP (protected EAP protocol).
Username The user name that was authenticated on the server.
Password Password of your username.
Click Save. Step 4
4.2.12 Configuring QoS
QoS can solve problems including network delay and congestion. It helps to assure bandwidth,
reduce transmission delay, packet loss rate and delay jitter to improve service quality.
For DSCP (Differentiated Services Code Point), there are 64 priority degrees (0-63) of data packets. 0
represents the lowest and 63 the highest. Based on those differences, the 64 priority degrees will be
classified as different groups. Each group occupies different bandwidth and will be abandoned
accordingly. The entire configuration is to improve video quality.
Select Setting > Network > QoS. Step 1
The QoS interface is displayed. See Figure 4-37.
QoS Figure 4-37
Set QoS parameters. See Table 4-21. Step 2
Table 4-21 QoS parameter description
Parameters Description
Real-time Monitor Priority of the data packets that are used for network surveillance.
Command
Priority degree used for the Camera’s configuration and check which do
not concern those surveillance data bags.
Click Save. Step 3
