Daihen OTC Almega AX Series User Manual

2.1 Connect Welding Interface (Digital)
2-2
3 Wire the signal cable, and connect the Welding Interface (Digital) Board CNCAN1 and
the Storage Board CNCAN.
4 Wire the 24V power supply cable, and connect the Welding interface (Digital) Board
CNP24V and the Sequence board TBEX3(P1), (M1). If the terminal block on the
Sequence Board is used for another purpose, connect the terminal to the Relay unit
TBIN1(24V), TBIN2(0V).
Figure 2.1.3 Cable wiring and connector connection
