3.8 Welding conditions of WB-M350L/M400L
3-23
3.8 Welding conditions of WB-M350L/M400L
This section describes the welding conditions that can be set when WB-M350L is connected.
3.8.1 About the welding condition parameters
The welding conditions that can be set when WB-M350L/M400L is connected using the interface
are shown in Table 3.8.1. Some welding conditions vary depending on the type of welding power
source registered in the robot controller. Welding condition parameters not included in this table
cannot be used.
Table 3.8.1 Welding conditions of WB-M350L/M400L
Welding conditions
Welding power source
registered in robot
controller
DL
DL(S-2)
AS
Welding process
○
*
1
○
*
1
Current cond.
○ ○
Welding current / Wire speed
○ ○
Welding voltage / Arc length tun.
○ ○
Welding speed
○ ○
Arc char.1(Short)
○ ○
Arc char.2(Arc)
○ ○
APCS cond.
○ ○
APCS parameter 1 / APCS parameter 1 EP
*
2
○ ○
APCS parameter 2 / APCS parameter 2 EP
*
2
○ ○
Slope time / Slope distance
○ ○
Initial current / Ini. wire speed
○ ○
Initial voltage / Ini. arc length
○ ○
Start adjust time
× ○
Start voltage adj
× ○
AE
Welding process
○
*
1
○
*
1
Current cond.
○ ○
Welding current / Wire speed ○ ○
Welding voltage / Arc length tun.
○ ○
Crater time ○ ○
Post flow time ○ ○
Arc char.1(Short)
○ ○
Arc char.2(Arc) ○ ○
APCS cond. ×
*
3
×
*
3
APCS parameter 1 / APCS parameter 1 EP
*
2
○ ○
APCS parameter 2 / APCS parameter 2 EP
*
2
○ ○
Slope time / Slope distance ○ ○
Burnback pulse
○ ○
Burnback pulse value
○ ○
○: Can be used
×: Cannot be used (operates with the initial value of the welding power source)
*1: The welding mode displayed on the robot controller may be different from the welding mode
of the Welbee Inverter welding power source. For details, see "3.4.2 Configuring the welding
mode for the Welbee Inverter series welding power source".
*2: The parameter names may be different depending on the welding power source, but the
functions are not different. For details on the functions, see "3.8.3 How the spatter
adjustment parameter (APCS cond.) is used" described later.
*3: Always set to "AUTO".
