3.11 Welding conditions of WB-P350L/P400L/P500L
3-46
3.11.7 Settgins on the Welding Power Source Side
In order to use the welding constants given below when WB-P500L is connected using this
device, it is necessary to configure the settings on the welding power source side.
・Torch
・Penetration adjustment function
・Arc voltage direct detection
・Process in the fan failure
・Process in the shortage of input voltage
The setting of these items can be managed on the screen of welding constants
when DPR is registered.
Turn on the power of welding power source.
By holding down Execute key, switch the keylock ON/OFF.
Change the function type from Normal to Almega.
The setting manner is as follows.
①
Hold down F key.
② The front panel indicates “F＊” blinking on its left side.
③ Hold down Execute key, switch the digital indication to “A＊”.
Move the kob on the front panel to align the digital indication on the left side to “A1”.
Press F key.
The digital indication on the right side blinks. Move the kob on the front panel under the
condition to set ON.
Configure the settings for each function. For the setting manner, see Table 3.11.6.
The function type can be switched by pressging Execute key.
It is available to change the number and s
ettings by moving the knob on the
front panel.
How to operate the welding power source:
F
or the details of operation manner for the welding power source, see the
instruction manual for welding poiwer supply.
