1.2 Main specifications
1-6
1.2.5 “Welding Interface (Digital) Setup” tool
To use Welding Interface (Digital), you must configure the interface settings on your computer
using the "Welding Interface (Digital) Setup" tool. For details, see "Chapter 3 Configurations".
To use this software, your system environment must comply with Table 1.2.5.
Table 1.2.5 System Requirements
Item Specifications
Operating System (Note 1) Windows XP, Windows 7(32bit), Windows10
Model IBM PC/AT compatible PC
CPU
Pentium III or higher processor (Pentium III 1 GHz or higher
is recommended)
Memory 256 MB or more
Hard disk More than 5 MB of available hard-disk space
Disc unit CD-ROM drive is mounted.
Personal
Computer
USB port (Note 2) One or more
Display
1024 768 dots or more
Required 64 MB or more
USB memory (Note 2)
Recommended
USB memory (1GB) for external storage:
L21700U00
Required 64 MB or more
CF card
(Required for obtaining the backup data)
Recommended
External storage CF (256 MB) for AXC:
L9742U00
CF card reader One or more (required for reading the backup data)
(Note 1) The product of our company develops and sells English version and Japanese version Windows as
operation guarantee target OS. Please acknowledge not guaranteeing operation on other language
versions Windows.
(Note 2) For this interface, USB memory is required when writing the setup data onto the Welding Interface
(Digital) board.
