Daihen OTC Almega AX Series User Manual

3.11 Welding conditions of WB-P350L/P400L/P500L
3-45
3.11.6 About the welding constants
The welding conditions that can be set when WB- P350L/P400L/P500L is connected using the
interface are shown in Table 3.11.5. Some welding conditions vary depending
on the type of welding power source registered in the robot controller. Welding condition
parameters not included in this table cannot be used.
Table 3.11.5 Welding conditions of WB- P350L/P400L/P500L
Item
Welding power source registration
DPR
DP
Inching/Retract speed ○ ○
Inching/Retract Key operation ○ ○
Gas check operation
○ ○
Preflow time ○ ○
Arc outage detect time ○ ○
Online modification cycle
○ ○
Auto. storing for online mod. ○ ○
Arc start failure detect time ○ ○
Arc start timing adjust time
○ ○
Arc start retry number ○ ○
Wire retract time ○ ○
Scratch start
○ ○
Waiting time after welding starts ○ ○
Arc end timing adjustment time ○ ○
Wire stick check
○ ○
Wire stick release time ○ ○
Torch ○ △
Penetration adjustment
○ △
WIF timeout check ○ ○
Restart retract distance ○ ○
Arc monitor display cycle
○ ○
Arc monitor sample data num ○ ○
Welding curr./volt. fail. act. ○ ○
Welding current failure limit
○ ○
Welding voltage failure limit ○ ○
RS contro;l ○ ○
Wire retract speed (RS control)
― ○
Wire retract offset time (RS control) ○ ○
Time rate of slow up ○ ○
Wire feed load fail action
○ ○
Wire feed load fail rate ○ ○
Stop welder at END ○ ○
WIF timeout check adjust.
○ ○
Arc outage detect. time (Arc End) ○ ○
Error determination time
(voltage detection line failure)
○ ○
Processing when fan error
○ △
Processing when volt shortage
○ △
Direct arc voltage detection
○ △
○: Can be used.
△: Perform settings on the front panel of welding
power source. For details, see “3.11.7
Settings on Welding Power Source Side”.
The settings made on the screen of welding
constants cannot be reflected.
―: Cannot be used
