Daihen OTC Almega AX Series User Manual

1.3 Standard configuration
1-10
Table 1.3.2 Configuration(TIG welder)
Ref.
No.
Parts Name
Model Type /
Part number
Specifications
Welding Interface
(Digital)
L22440A00 Refer to Table 1.2.1
Welding Interface
(Digital) board
L22440C00 Installed inside the robot controller
Fuse (F1)
2171.25MXP
(Parts number:
100-1742)
Rated 250V - 1.25A, UL, CSA, CCC certified product
Communication
cable
L22440E00 between Storage board and Welding Interface (Digital) board
(1)
Power cable L22440J00 for power supply 24V
L-7623E Cable length 6m
L-7623J Cable length 10m
For air cool ing, 200A torch
L-7633E Cable length 6m
Power cable
(torch side)
L-7633J Cable length 10m
For water cool ing, 350A torch
BBAWD-1701 For air cool ing, 200A torch
Torch adapter
BBAWD-1801 For water cool ing, 350A torch
Torch side welding cable BKPDT-6007 Cable length 5m
(2)
Gas hose
BKHGFF-0603 Cable length 3m
(3) TIG filler controller HC-71D (E2448) With filler feeding unit
(4) CAV I/F board L23139A With filler feeding unit
(5)
CAN communication
cable
L23306*00
With filler feeding unit
* B： 1m
C： 5m
(6) Control cable 4
L9610*00
With filler feeding unit
* B： 5m
C： 10m
D： 15m
(7) Control cable 5
A2RB-52**
** 05：
10：
15：
5m
（for Welbee Inverter）
10m
（for Welbee Inverter）
15m（for Welbee Inverter）
