1.4 Welding mode lists
1-23
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MAG
Mild Steel
Cored
1.2 Standard 400A Mag DC φ1.2 (Cored) (Low) $WTBD3073
〃 〃
SUS
Cored
1.2 〃 400A Mag DC φ1.2 SuS(Cored) (Low) $WTBD3074
〃 MAG※1
Mild Steel
Solid
0.8 〃 400A Mag_1 DC φ0.8 (Low) $WTBD3075
〃 〃 〃 1.0 〃 400A Mag_1 DC φ1.0 (Low) $WTBD3077
〃 〃 〃 1.2 〃 400A Mag_1 DC φ1.2 (Low) $WTBD3078
〃 MIG※2 SUS 0.8 〃 400A Mig_2 DC φ0.8 SuS (Low) $WTBD3079
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 SuS (Low) $WTBD3081
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 SuS (Low) $WTBD3082
〃 〃 Ferrite 0.8 〃 400A Mig_2 DC φ0.8 Ferrite (Low) $WTBD3083
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 Ferrite (Low) $WTBD3085
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 Ferrite (Low) $WTBD3086
〃 MIG※4 〃 0.8 〃 400A Mig_4 DC φ0.8 Ferrite (Low) $WTBD3087
〃 〃 〃 1.0 〃 400A Mig_4 DC φ1.0 Ferrite (Low) $WTBD3089
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite (Low) $WTBD3090
〃 MIG※3 Hard Alm 1.0 〃 400A Mig_3 DC φ1.0 Hard Al (Low) $WTBD3091
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Hard Al (Low) $WTBD3092
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Hard Al (Low) $WTBD3093
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC φ1.2 Soft Al (Low) $WTBD3094
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Soft Al (Low) $WTBD3095
〃 〃 Cu-Si 0.8 〃 400A Mig_3 DC φ0.8 Cu-Si (Low) $WTBD3096
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Si (Low) $WTBD3098
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Si (Low) $WTBD3099
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC φ0.8 Cu-Al (Low) $WTBD3100
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Al (Low) $WTBD3102
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Al (Low) $WTBD3103
〃 MAG
Mild Steel
Cored
1.2
Extended
cable
400A Mag DC φ1.2 (Cored) (Low*) $WTBD3104
〃 〃
SUS
Cored
1.2
〃 400A Mag DC φ1.2 SuS(Cored) (Low*) $WTBD3105
〃 MAG※1
Mild Steel
Solid
0.8 〃 400A Mag_1 DC φ0.8 (Low*) $WTBD3106
〃 〃 〃 1.0 〃 400A Mag_1 DC φ1.0 (Low*) $WTBD3108
〃 〃 〃 1.2 〃 400A Mag_1 DC φ1.2 (Low*) $WTBD3109
〃 MIG※2 SUS 0.8 〃 400A Mig_2 DC φ0.8 SuS (Low*) $WTBD3110
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 SuS (Low*) $WTBD3112
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 SuS (Low*) $WTBD3113
〃 〃 Ferrite 0.8 〃 400A Mig_2 DC φ0.8 Ferrite (Low*) $WTBD3114
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 Ferrite (Low*) $WTBD3116
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 Ferrite (Low*) $WTBD3117
〃 MIG※4 〃 0.8 〃 400A Mig_4 DC φ0.8 Ferrite (Low*) $WTBD3118
〃 〃 〃 1.0 〃 400A Mig_4 DC φ1.0 Ferrite (Low*) $WTBD3120
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite (Low*) $WTBD3121
〃 MIG※3 Hard Alm 1.0 〃 400A Mig_3 DC φ1.0 Hard Al (Low*) $WTBD3122
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Hard Al (Low*) $WTBD3123
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Hard Al (Low*) $WTBD3124
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC φ1.2 Soft Al (Low*) $WTBD3125
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Soft Al (Low*) $WTBD3126
〃 〃 Cu-Si 0.8 〃 400A Mig_3 DC φ0.8 Cu-Si (Low*) $WTBD3127
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Si (Low*) $WTBD3129
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Si (Low*) $WTBD3130
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC φ0.8 Cu-Al (Low*) $WTBD3131
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Al (Low*) $WTBD3133
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Al (Low*) $WTBD3134
※1 90%Ar, 10%CO
2
※2 97.5%Ar, 2.5%CO
2
※3 100%Ar
※4 98%Ar, 2%O
2
