1.4 Welding mode lists
1-30
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MIG※3 Cu-Si 1.0 High 500A Mig_3 DC φ1.0 Cu-Si (High) $WTBD3275
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Si (High) $WTBD3276
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC φ0.8 Cu-Al (High) $WTBD3277
〃 〃 〃 1.0 〃 500A Mig_3 DC φ1.0 Cu-Al (High) $WTBD3279
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Al (High) $WTBD3280
〃 MAG
Mild Steel
Cored
1.2 Standard 500A Mag DC φ1.2 (Cored) (Low) $WTBD3281
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 (Cored) (Low) $WTBD3282
〃 〃 SUS Cored 1.2 〃 500A Mag DC φ1.2 SuS(Cored) (Low) $WTBD3283
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 SuS(Cored) (Low) $WTBD3284
〃 MAG※1
Mild Steel
Solid
0.8 〃 500A Mag_1 DC φ0.8 (Low) $WTBD3285
〃 〃 〃 1.0 〃 500A Mag_1 DC φ1.0 (Low) $WTBD3287
〃 〃 〃 1.2 〃 500A Mag_1 DC φ1.2 (Low) $WTBD3288
〃 MIG※2 SUS 0.8 〃 500A Mig_2 DC φ0.8 SuS (Low) $WTBD3289
〃 〃 〃 1.0 〃 500A Mig_2 DC φ1.0 SuS (Low) $WTBD3291
〃 〃 〃 1.2 〃 500A Mig_2 DC φ1.2 SuS (Low) $WTBD3292
〃 〃 〃 1.6 〃 500A Mig_2 DC φ1.6 SuS (Low) $WTBD3293
〃 MIG※4 Ferrite 1.2 〃 500A Mig_4 DC φ1.2 Ferrite (Low) $WTBD3294
〃 MIG※3 Hard Alm 1.0 〃 500A Mig_3 DC φ1.0 Hard Al (Low) $WTBD3295
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Hard Al (Low) $WTBD3296
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Hard Al (Low) $WTBD3297
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC φ1.2 Soft Al (Low) $WTBD3298
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Soft Al (Low) $WTBD3299
〃 〃 Cu-Si 0.8 〃 500A Mig_3 DC φ0.8 Cu-Si (Low) $WTBD3300
〃 〃 〃 1.0 〃 500A Mig_3 DC φ1.0 Cu-Si (Low) $WTBD3302
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Si (Low) $WTBD3303
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC φ0.8 Cu-Al (Low) $WTBD3304
〃 〃 〃 1.0 〃 500A Mig_3 DC φ1.0 Cu-Al (Low) $WTBD3306
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Al (Low) $WTBD3307
〃 MAG
Mild Steel
Cored
1.2
Extended
cable
500A Mag DC φ1.2 (Cored) (Low*) $WTBD3308
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 (Cored) (Low*) $WTBD3309
〃 〃 SUS Cored 1.2 〃 500A Mag DC φ1.2 SuS(Cored) (Low*) $WTBD3310
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 SuS(Cored) (Low*) $WTBD3311
〃 MAG※1
Mild Steel
Solid
0.8 〃 500A Mag_1 DC φ0.8 (Low*) $WTBD3312
〃 〃 〃 1.0 〃 500A Mag_1 DC φ1.0 (Low*) $WTBD3314
〃 〃 〃 1.2 〃 500A Mag_1 DC φ1.2 (Low*) $WTBD3315
〃 MIG※2 SUS 0.8 〃 500A Mig_2 DC φ0.8 SuS (Low*) $WTBD3316
〃 〃 〃 1.0 〃 500A Mig_2 DC φ1.0 SuS (Low*) $WTBD3318
〃 〃 〃 1.2 〃 500A Mig_2 DC φ1.2 SuS (Low*) $WTBD3319
〃 〃 〃 1.6 〃 500A Mig_2 DC φ1.6 SuS (Low*) $WTBD3320
〃 MIG※4 Ferrite 1.2 〃 500A Mig_4 DC φ1.2 Ferrite (Low*) $WTBD3321
〃 MIG※3 Hard Alm 1.0 〃 500A Mig_3 DC φ1.0 Hard Al (Low*) $WTBD3322
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Hard Al (Low*) $WTBD3323
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Hard Al (Low*) $WTBD3324
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC φ1.2 Soft Al (Low*) $WTBD3325
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Soft Al (Low*) $WTBD3326
〃 〃 Cu-Si 0.8 〃 500A Mig_3 DC φ0.8 Cu-Si (Low*) $WTBD3327
〃 〃 〃 1.0 〃 500A Mig_3 DC φ1.0 Cu-Si (Low*) $WTBD3329
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Si (Low*) $WTBD3330
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC φ0.8 Cu-Al (Low*) $WTBD3331
〃 〃 〃 1.0 〃 500A Mig_3 DC φ1.0 Cu-Al (Low*) $WTBD3333
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Al (Low*) $WTBD3334
※1 90%Ar, 10%CO
2
※2 97.5%Ar, 2.5%CO
2
※3 100%Ar
※4 98%Ar, 2%O
2
