1.4 Welding mode lists
1-33
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC
pulse
MIG※2 Hard Alm 1.0 Standard 350A Mig_3 DC-Pulse φ1.0 Hard Al(Low) $WTBD3559
〃 〃 〃 1.2 〃 350A Mig_3 DC-Pulse φ1.2 Hard Al(Low) $WTBD3560
〃 〃 〃 1.6 〃 350A Mig_3 DC-Pulse φ1.6 Hard Al(Low) $WTBD3561
〃 〃 Soft Alm 1.2 〃 350A Mig_3 DC-Pulse φ1.2 Soft Al(Low) $WTBD3562
〃 〃 〃 1.6 〃 350A Mig_3 DC-Pulse φ1.6 Soft Al(Low) $WTBD3563
DC CO2
Mild Steel
Solid
0.8
Extended
cable
350A Co2 DC φ0.8(Low*) $WTBD3564
〃 〃 〃 0.9 〃 350A Co2 DC φ0.9(Low*) $WTBD3565
〃 〃 〃 1.0 〃 350A Co2 DC φ1.0(Low*) $WTBD3566
〃 〃 〃 1.2 〃 350A Co2 DC φ1.2(Low*) $WTBD3567
〃 〃
Mild Steel
Cored
1.0 〃 350A Co2 DC φ1.0 (Cored) (Low*) $WTBD3568
〃 〃 〃 1.2 〃 350A Co2 DC φ1.2 (Cored) (Low*) $WTBD3569
〃 〃 SUS Cored 0.9 〃 350A Co2 DC φ0.9 SuS(Cored) (Low*) $WTBD3570
〃 〃 〃 1.2 〃 350A Co2 DC φ1.2 SuS(Cored) (Low*) $WTBD3571
〃 MAG
Mild Steel
Solid
0.8 〃 350A Mag DC φ0.8(Low*) $WTBD3572
〃 〃 〃 0.9 〃 350A Mag DC φ0.9(Low*) $WTBD3573
〃 〃 〃 1.0 〃 350A Mag DC φ1.0(Low*) $WTBD3574
〃 〃 〃 1.2 〃 350A Mag DC φ1.2(Low*) $WTBD3575
〃 MIG※1 SUS 0.8 〃 350A Mig_4 DC φ0.8 SuS(Low*) $WTBD3576
〃 〃 〃 0.9 〃 350A Mig_4 DC φ0.9 SuS(Low*) $WTBD3577
〃 〃 〃 1.0 〃 350A Mig_4 DC φ1.0 SuS(Low*) $WTBD3578
〃 〃 〃 1.2 〃 350A Mig_4 DC φ1.2 SuS(Low*) $WTBD3579
〃 MIG※2 Hard Alm 1.0 〃 350A Mig_3 DC φ1.0 Hard Al(Low*) $WTBD3580
〃 〃 〃 1.2 〃 350A Mig_3 DC φ1.2 Hard Al(Low*) $WTBD3581
〃 〃 〃 1.6 〃 350A Mig_3 DC φ1.6 Hard Al(Low*) $WTBD3582
〃 〃 Soft Alm 1.2 〃 350A Mig_3 DC φ1.2 Soft Al(Low*) $WTBD3583
〃 〃 〃 1.6 〃 350A Mig_3 DC φ1.6 Soft Al(Low*) $WTBD3584
DC
wave
pulse
MAG
Mild Steel
Solid
0.9 High 350A Mag DC-Wave φ0.9(High) $WTBD3585
〃 〃 〃 1.0 〃 350A Mag DC-Wave φ1.0(High) $WTBD3586
〃 〃 〃 1.2 〃 350A Mag DC-Wave φ1.2(High) $WTBD3587
〃 MIG※1 SUS 0.9 〃 350A Mig_4 DC-Wave φ0.9 SuS(High) $WTBD3588
〃 〃 〃 1.0 〃 350A Mig_4 DC-Wave φ1.0 SuS(High) $WTBD3589
〃 〃 〃 1.2 〃 350A Mig_4 DC-Wave φ1.2 SuS(High) $WTBD3590
〃 MIG※2 Hard Alm 1.2 〃 350A Mig_3 DC-Wave φ1.2 Hard Al(High) $WTBD3591
〃 〃 〃 1.6 〃 350A Mig_3 DC-Wave φ1.6 Hard Al(High) $WTBD3592
〃 〃 Soft Alm 1.2 〃 350A Mig_3 DC-Wave φ1.2 Soft Al(High) $WTBD3593
〃 〃 〃 1.6 〃 350A Mig_3 DC-Wave φ1.6 Soft Al(High) $WTBD3594
〃 MAG
Mild Steel
Solid
0.9 Standard 350A Mag DC-Wave φ0.9(Low) $WTBD3595
DC
wave
pulse
〃 〃 1.0 〃 350A Mag DC-Wave φ1.0(Low) $WTBD3596
〃 〃 〃 1.2 〃 350A Mag DC-Wave φ1.2(Low) $WTBD3597
〃 MIG※1 SUS 0.9 〃 350A Mig_4 DC-Wave φ0.9 SuS(Low) $WTBD3598
〃 〃 〃 1.0 〃 350A Mig_4 DC-Wave φ1.0 SuS(Low) $WTBD3599
〃 〃 〃 1.2 〃 350A Mig_4 DC-Wave φ1.2 SuS(Low) $WTBD3600
〃 MIG※2 Hard Alm 1.2 〃 350A Mig_3 DC-Wave φ1.2 Hard Al(Low) $WTBD3601
〃 〃 〃 1.6 〃 350A Mig_3 DC-Wave φ1.6 Hard Al(Low) $WTBD3602
〃 〃 Soft Alm 1.2 〃 350A Mig_3 DC-Wave φ1.2 Soft Al(Low) $WTBD3603
〃 〃 〃 1.6 〃 350A Mig_3 DC-Wave φ1.6 Soft Al(Low) $WTBD3604
〃 〃 Hard Alm 1.0 〃 350A Mig_3 DC-Wave φ1.0 Hard Al(High) $WTBD3691
〃 〃 〃 1.0 〃 350A Mig_3 DC-Wave φ1.0 Hard Al(Low) $WTBD3761
※1 98%Ar, 2%O
2
※2 100%Ar
