1.4 Welding mode lists
1-40
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC
pulse
MIG※4 Ferrite 1.0 High 400A Mig_4 DC-Pulseφ1.0 Ferrite (High) $WTBD3655
〃 〃 〃 1.2 〃 400A Mig_4 DC-Pulseφ1.2 Ferrite (High) $WTBD3656
〃 MIG※3 SUS 1.0 〃 400A Mig_3 DC-Pulseφ1.0 SuS (High) $WTBD3657
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 SuS (High) $WTBD3658
〃 〃 Ferrite 1.0 〃 400A Mig_3 DC-Pulseφ1.0 Ferrite (High) $WTBD3659
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Ferrite (High) $WTBD3660
〃 〃 Cu-Si 0.8 〃 400A Mig_3 DC-Pulseφ0.8 Cu-Si (High) $WTBD3661
〃 〃 〃 1.0 〃 400A Mig_3 DC-Pulseφ1.0 Cu-Si (High) $WTBD3663
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Cu-Si (High) $WTBD3664
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC-Pulseφ0.8 Cu-Al (High) $WTBD3665
〃 〃 〃 1.0 〃 400A Mig_3 DC-Pulseφ1.0 Cu-Al (High) $WTBD3667
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Cu-Al (High) $WTBD3668
〃 〃 Inconel 0.9 〃 400A Mig_3 DC-Pulseφ0.9 Inconel (High) $WTBD3669
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Inconel (High) $WTBD3670
〃 〃 Titanium 1.0 〃
400A Mig_3 DC-Pulseφ1.0 Titanium
(High)
$WTBD3671
〃 〃 〃 1.2 〃
400A Mig_3 DC-Pulseφ1.2 Titanium
(High)
$WTBD3672
DC
wave
pulse
MAG
Mild Steel
Solid
0.8 〃 400A Mag DC-Waveφ0.8 (High) $WTBD3673
〃 MAG※1 〃 0.8 〃 400A Mag_1 DC-Waveφ0.8 (High) $WTBD3674
〃 〃 〃 1.0 〃 400A Mag_1 DC-Waveφ1.0 (High) $WTBD3676
〃 〃 〃 1.2 〃 400A Mag_1 DC-Waveφ1.2 (High) $WTBD3677
〃 MIG※2 SUS 0.8 〃 400A Mig_2 DC-Waveφ0.8 SuS (High) $WTBD3678
〃 〃 〃 1.0 〃 400A Mig_2 DC-Waveφ1.0 SuS (High) $WTBD3680
〃 〃 〃 1.2 〃 400A Mig_2 DC-Waveφ1.2 SuS (High) $WTBD3681
DC
wave
pulse
MIG※2 Ferrite 0.8 High 400A Mig_2 DC-Waveφ0.8 Ferrite (High) $WTBD3682
〃 〃 〃 1.0 〃 400A Mig_2 DC-Waveφ1.0 Ferrite (High) $WTBD3684
〃 〃 〃 1.2 〃 400A Mig_2 DC-Waveφ1.2 Ferrite (High) $WTBD3685
〃 MIG※4 SUS 0.8 〃 400A Mig_4 DC-Waveφ0.8 SuS (High) $WTBD3686
〃 〃 Ferrite 0.8 〃 400A Mig_4 DC-Waveφ0.8 Ferrite (High) $WTBD3687
〃 〃 〃 1.0 〃 400A Mig_4 DC-Waveφ1.0 Ferrite (High) $WTBD3689
〃 〃 〃 1.2 〃 400A Mig_4 DC-Waveφ1.2 Ferrite (High) $WTBD3690
〃 MIG※3 Hard Alm 1.0 〃 400A Mig_3 DC-Waveφ1.0 Hard Al (High) $WTBD3691
DC MAG
Mild Steel
Cored
1.2 Standard 400A Mag DCφ1.2 (Cored) (Low) $WTBD3693
〃 〃 SUS Cored 1.2 〃 400A Mag DCφ1.2 SuS(Cored) (Low) $WTBD3694
〃 MAG※1
Mild Steel
Solid
0.8 〃 400A Mag_1 DCφ0.8 (Low) $WTBD3695
〃 〃 〃 1.0 〃 400A Mag_1 DCφ1.0 (Low) $WTBD3697
〃 〃 〃 1.2 〃 400A Mag_1 DCφ1.2 (Low) $WTBD3698
〃 MIG※2 SUS 0.8 〃 400A Mig_2 DCφ0.8 SuS (Low) $WTBD3699
〃 〃 〃 1.0 〃 400A Mig_2 DCφ1.0 SuS (Low) $WTBD3701
〃 〃 〃 1.2 〃 400A Mig_2 DCφ1.2 SuS (Low) $WTBD3702
〃 〃 Ferrite 1.0 〃 400A Mig_2 DCφ1.0 Ferrite (Low) $WTBD3703
〃 〃 〃 1.2 〃 400A Mig_2 DCφ1.2 Ferrite (Low) $WTBD3704
DC
pulse
MAG※1
Mild Steel
Solid
0.8 〃 400A Mag_1 DC-Pulseφ0.8 (Low) $WTBD3707
〃 〃 〃 1.0 〃 400A Mag_1 DC-Pulseφ1.0 (Low) $WTBD3709
〃 〃 〃 1.2 〃 400A Mag_1 DC-Pulseφ1.2 (Low) $WTBD3710
〃 MIG※2 SUS 0.8 〃 400A Mig_2 DC-Pulseφ0.8 SuS (Low) $WTBD3711
〃 〃 〃 1.0 〃 400A Mig_2 DC-Pulseφ1.0 SuS (Low) $WTBD3713
〃 〃 〃 1.2 〃 400A Mig_2 DC-Pulseφ1.2 SuS (Low) $WTBD3714
〃 〃 Ferrite 0.8 〃 400A Mig_2 DC-Pulseφ0.8 Ferrite (Low) $WTBD3715
〃 〃 〃 1.0 〃 400A Mig_2 DC-Pulseφ1.0 Ferrite (Low) $WTBD3717
〃 〃 〃 1.2 〃 400A Mig_2 DC-Pulseφ1.2 Ferrite (Low) $WTBD3718
〃 MIG※4 SUS 0.8 〃 400A Mig_4 DC-Pulseφ0.8 SuS (Low) $WTBD3719
〃 〃 Ferrite 0.8 〃 400A Mig_4 DC-Pulseφ0.8 Ferrite (Low) $WTBD3720
〃 〃 〃 1.0 〃 400A Mig_4 DC-Pulseφ1.0 Ferrite (Low) $WTBD3722
〃 〃 〃 1.2 〃 400A Mig_4 DC-Pulseφ1.2 Ferrite (Low) $WTBD3723
〃 MIG※3 SUS 1.0 〃 400A Mig_3 DC-Pulseφ1.0 SuS (Low) $WTBD3724
