1.4 Welding mode lists
1-58
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
File comment
Notes
Number of
welding
characteristic
data in
AX21/FD11
〃 〃 〃 1.0 〃 400A Mig_3 DC-Pulse φ1.0 Cu-Si (Low) $WTBD10284
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Si (Low) $WTBD10285
〃 〃
Aluminum
Bronze
0.8 〃 400A Mig_3 DC-Pulse φ0.8 Cu-Al (Low) $WTBD10286
〃 〃 〃 1.0 〃 400A Mig_3 DC-Pulse φ1.0 Cu-Al (Low) $WTBD10288
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Al (Low) $WTBD10289
〃 〃 Inconel 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Inconel (Low) $WTBD10290
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Inconel (Low) $WTBD10291
〃 〃 Titanium 1.0 〃 400A Mig_3 DC-Pulse φ1.0 Titanium (Low) $WTBD10292
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Titanium (Low) $WTBD10293
DC
wave
pulse ﾞ
Mag※2
Mild Steel
Solid
0.8 〃 400A Mag_1 DC-Wave φ0.8 (Low) $WTBD10294
〃 〃 〃 1.0 〃 400A Mag_1 DC-Wave φ1.0 (Low) $WTBD10295
〃 〃 〃 1.2 〃 400A Mag_1 DC-Wave φ1.2 (Low) $WTBD10296
〃 Mig※3 SUS 0.8 〃 400A Mig_2 DC-Wave φ0.8 SuS (Low) $WTBD10297
〃 〃 〃 1.0 〃 400A Mig_2 DC-Wave φ1.0 SuS (Low) $WTBD10298
〃 〃 〃 1.2 〃 400A Mig_2 DC-Wave φ1.2 SuS (Low) $WTBD10299
〃 〃 Ferrite 0.8 〃 400A Mig_2 DC-Wave φ0.8 Ferrite (Low) $WTBD10300
〃 〃 〃 1.0 〃 400A Mig_2 DC-Wave φ1.0 Ferrite (Low) $WTBD10301
〃 〃 〃 1.2 〃 400A Mig_2 DC-Wave φ1.2 Ferrite (Low) $WTBD10302
DC Mag※1
Mild Steel
Cored
1.2
Extended
cable
400A Mag DCφ1.2 (Cored) (Low*) $WTBD10303
〃 〃
SUS
CORED
1.2 〃 400A Mag DCφ1.2 SuS(Cored) (Low*) $WTBD10305
〃 Mag※2
Mild Steel
Solid
0.8 〃 400A Mag_1 DC φ0.8 (Low*) $WTBD10306
〃 〃 〃 1.0 〃 400A Mag_1 DC φ1.0 (Low*) $WTBD10307
〃 〃 〃 1.2 〃 400A Mag_1 DC φ1.2 (Low*) $WTBD10308
〃 Mig※3 SUS 0.8 〃 400A Mig_2 DC φ0.8 SuS (Low*) $WTBD10309
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 SuS (Low*) $WTBD10310
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 SuS (Low*) $WTBD10311
〃 〃 Ferrite 0.8 〃 400A Mig_2 DC φ0.8 Ferrite (Low*) $WTBD10312
〃 〃 〃 1.0 〃 400A Mig_2 DC φ1.0 Ferrite (Low*) $WTBD10313
〃 〃 〃 1.2 〃 400A Mig_2 DC φ1.2 Ferrite (Low*) $WTBD10314
〃 Mig※5
Silicon
Bronze
0.8 〃 400A Mig_3 DC φ0.8 Cu-Si (Low*) $WTBD10315
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Si (Low*) $WTBD10317
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Si (Low*) $WTBD10318
〃 〃
Aluminum
Bronze
0.8 〃 400A Mig_3 DC φ0.8 Cu-Al (Low*) $WTBD10319
〃 〃 〃 1.0 〃 400A Mig_3 DC φ1.0 Cu-Al (Low*) $WTBD10321
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Al (Low*) $WTBD10322
※1 80%Ar, 20%Co
2
※2 90%Ar, 10%Co
2
※3 97.5%Ar, 2.5%Co
2
※4 98%Ar, 2%O
2
※5 100%Ar
POINT
Normally, use the welding characteristic data given in Table 1.4.20 dedicated to
“High” application. The ones for “Standard” application must be used only when the
welding speed is low (50cm/min or lower in general), which causes unstable welding
performance.
Also, welding performance may become unstable when using the extended power cable
depending on the layout condition of cables (when the total length exceeds 30m or the
cable is coiled). In that case, voltage adjustment will normally bring about stable
condition. However, use the welding characteristic data dedicated to “Standard:
extension” application if the welding performance is not yet stable. In order to register
“Standard: extension” application, change the operator qualification to “
SPECIALIST
”.)
