Daihen OTC Almega AX Series User Manual

1.4 Welding mode lists
1-62
Welding mode
Welding
process
Gas
Wire
material
Wire
diamet
er
Travel
speed
File comment
Notes
Number of
welding
characteristic
data in
AX21/FD11
〃 〃 〃 0.9 〃 400A Mig_4 DC φ0.9 Ferrite(Low*) $WTBD10131
〃 〃 〃 1.0 〃 400A Mig_4 DC φ1.0 Ferrite(Low*) $WTBD10132
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite(Low*) $WTBD10133
〃 MIG※2 Hard Alm 1.0 〃 400A Mig_3 DC φ1.0 Hard Al(Low*) $WTBD10134
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Hard Al(Low*) $WTBD10135
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Hard Al(Low*) $WTBD10136
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC φ1.2 Soft Al(Low*) $WTBD10137
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Soft Al(Low*) $WTBD10138
DC
wave
pulse
MAG
Mild Steel
Solid
0.8 High 400A Mag DC-Wave φ0.8(High) $WTBD10139
〃 〃 〃 0.9 〃 400A Mag DC-Wave φ0.9(High) $WTBD10140
〃 〃 〃 1.0 〃 400A Mag DC-Wave φ1.0(High) $WTBD10141
〃 〃 〃 1.2 〃 400A Mag DC-Wave φ1.2(High) $WTBD10142
〃 MIG※1 SUS 0.8 〃 400A Mig_4 DC-Wave φ0.8 SuS(High) $WTBD10143
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 SuS(High) $WTBD10144
〃 〃 〃 1.0 〃 400A Mig_4 DC-Wave φ1.0 SuS(High) $WTBD10145
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 SuS(High) $WTBD10146
〃 〃 Ferrite 0.8 〃 400A Mig_4 DC-Wave φ0.8 Ferrite(High) $WTBD10147
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 Ferrite(High) $WTBD10148
〃 〃 〃 1.0 〃 400A Mig_4 DC-Wave φ1.0 Ferrite(High) $WTBD10149
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 Ferrite(High) $WTBD10150
〃 MIG※2 Hard Alm 1.0 〃 400A Mig_3 DC-Wave φ1.0 Hard Al(High) $WTBD10151
〃 〃 〃 1.2 〃 400A Mig_3 DC-Wave φ1.2 Hard Al(High) $WTBD10152
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Hard Al(High) $WTBD10153
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Soft Al(High) $WTBD10154
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Soft Al(High) $WTBD10155
〃 MAG
Mild Steel
Solid
0.8 Standard 400A Mag DC-Wave φ0.8(Low) $WTBD10156
〃 〃 〃 0.9 〃 400A Mag DC-Wave φ0.9(Low) $WTBD10157
〃 〃 〃 1.0 〃 400A Mag DC-Wave φ1.0(Low) $WTBD10158
〃 〃 〃 1.2 〃 400A Mag DC-Wave φ1.2(Low) $WTBD10159
〃 MIG※1 SUS 0.8 〃 400A Mig_4 DC-Wave φ0.8 SuS(Low) $WTBD10160
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 SuS(Low) $WTBD10161
〃 〃 〃 1.0 〃 400A Mig_4 DC-Wave φ1.0 SuS(Low) $WTBD10162
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 SuS(Low) $WTBD10163
〃 〃 Ferrite 0.8 〃 400A Mig_4 DC-Wave φ0.8 Ferrite(Low) $WTBD10164
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 Ferrite(Low) $WTBD10165
〃 〃 〃 1.0 〃 400A Mig_4 DC-Wave φ1.0 Ferrite(Low) $WTBD10166
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 Ferrite(Low) $WTBD10167
〃 MIG※2 Hard Alm 1.0 〃 400A Mig_3 DC-Wave φ1.0 Hard Al(Low) $WTBD10168
〃 〃 〃 1.2 〃 400A Mig_3 DC-Wave φ1.2 Hard Al(Low) $WTBD10169
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Hard Al(Low) $WTBD10170
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Soft Al(Low) $WTBD10171
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Soft Al(Low) $WTBD10172
※1 98%Ar, 2%O
2
※2 100%Ar
POINT
Normally, use the welding characteristic data given in Table 1.4.17 dedicated to “High”
application. The ones for “Standard” application must be used only when the welding
speed is low (50cm/min or lower in general), which causes unstable welding
performance.
Also, welding performance may become unstable when using the extended power cable
depending on the layout condition of cables (when the total length exceeds 30m or the
cable is coiled). In that case, voltage adjustment will normally bring about stable
condition. However, use the welding characteristic data dedicated to “Standard:
extension” application if the welding performance is not yet stable. In order to register
“Standard: extension” application, change the operator qualification to “ SPECIALIST ”.)
