1.4 Welding mode lists
1-70
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MIG※3 Cu-Al 1.2 Standard 500A Mig_3 DC φ1.2 Cu-Al (Low) $WTBD4120
DC
pulse
〃 Cu-Si 0.8 〃 500A Mig_3 DC-Pulse φ0.8 Cu-Si (Low) $WTBD4125
〃 〃 〃 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Cu-Si (Low) $WTBD4126
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Cu-Si (Low) $WTBD4128
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC-Pulse φ0.8 Cu-Al (Low) $WTBD4129
〃 〃 〃 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Cu-Al (Low) $WTBD4130
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Cu-Al (Low) $WTBD4132
〃 〃 Cu-Si 0.8 High 500A Mig_3 DC-Pulse φ0.8 Cu-Si (High) $WTBD4179
〃 〃 〃 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Cu-Si (High) $WTBD4180
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Cu-Si (High) $WTBD4182
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC-Pulse φ0.8 Cu-Al (High) $WTBD4183
〃 〃 〃 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Cu-Al (High) $WTBD4184
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Cu-Al (High) $WTBD4186
〃 〃 INCONEL 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Inconel (High) $WTBD4187
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Inconel (High) $WTBD4188
DC MAG
Mild Steel
Cored
1.2 Standard 500A Mag DC φ1.2 (Cored) (Low) $WTBD4205
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 (Cored) (Low) $WTBD4206
〃 〃 SUS 1.2 〃 500A Mag DC φ1.2 SuS(Cored) (Low) $WTBD4207
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 SuS(Cored) (Low) $WTBD4208
DC
pulse
MIG※3 INCONEL 0.9 〃 500A Mig_3 DC-Pulse φ0.9 Inconel (Low) $WTBD4255
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Inconel (Low) $WTBD4256
DC MAG
Mild Steel
Cored
1.2
Extended
cable
500A Mag DC φ1.2 (Cored) (Low*) $WTBD4273
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 (Cored) (Low*) $WTBD4274
〃 〃 SUS 1.2 〃 500A Mag DC φ1.2 SuS(Cored) (Low*) $WTBD4275
〃 〃 〃 1.6 〃 500A Mag DC φ1.6 SuS(Cored) (Low*) $WTBD4276
〃 MIG Cu-Si 0.8 〃 500A Mig_3 DC φ0.8 Cu-Si (Low*) $WTBD4291
〃 〃 〃 0.9 〃 500A Mig_3 DC φ0.9 Cu-Si (Low*) $WTBD4292
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Si (Low*) $WTBD4294
〃 〃 Cu-Al 0.8 〃 500A Mig_3 DC φ0.8 Cu-Al (Low*) $WTBD4295
〃 〃 〃 0.9 〃 500A Mig_3 DC φ0.9 Cu-Al (Low*) $WTBD4296
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Cu-Al (Low*) $WTBD4298
〃 MAG
Mild Steel
Cored
1.4 Standard 500A Mag DC φ1.4 (Cored) (Low) $WTBD4305
〃 〃 〃 1.4
Extended
cable
500A Mag DC φ1.4 (Cored) (Low*) $WTBD4306
DC
pulse
MIG※5
J-Solution
Zn
1.0 High
500A Mig_2 DC-Pulse φ1.0 J-Sol.
Zn(High)
$WTBD4307(*)
〃 〃 〃 1.2 〃
500A Mig_2 DC-Pulse φ1.2 J-Sol.
Zn(High)
$WTBD4308(*)
DC
wave
pulse
〃 〃 1.0 〃
500A Mig_2 DC-Wave φ1.0 J-Sol.
Zn(High)
$WTBD4309(*)
〃 〃 〃 1.2 〃
500A Mig_2 DC-Wave φ1.2 J-Sol.
Zn(High)
$WTBD4310(*)
(*) : This is a optional mode.
※1 90%Ar, 10%CO
2
※2 98%Ar, 2%O
2
※3 100%Ar
※4 98%Ar, 2%O
2
※5 70%Ar, 30%CO
2
To Next Page
