1.4 Welding mode lists
1-73
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MIG※4 SUS 0.8 Standard 500A Mig_4 DCφ0.8 SuS (Low) $WTBD3990
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 SuS (Low) $WTBD3992
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 SuS (Low) $WTBD3993
〃 〃 〃 1.6 〃 500A Mig_4 DCφ1.6 SuS (Low) $WTBD3994
〃 〃 Ferrite 0.8 〃 500A Mig_4 DCφ0.8 Ferrite (Low) $WTBD3995
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 Ferrite (Low) $WTBD3997
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 Ferrite (Low) $WTBD3998
〃 MIG※3 Hard Alm 1.0 〃 500A Mig_3 DCφ1.0 Hard Al (Low) $WTBD3999
〃 〃 〃 1.2 〃 500A Mig_3 DCφ1.2 Hard Al (Low) $WTBD4000
〃 〃 〃 1.6 〃 500A Mig_3 DCφ1.6 Hard Al (Low) $WTBD4001
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DCφ1.2 Soft Al (Low) $WTBD4002
〃 〃 〃 1.6 〃 500A Mig_3 DCφ1.6 Soft Al (Low) $WTBD4003
〃 CO2
Mild Steel
Solid
0.8 〃 500A Co2 DCφ0.8 (Low#) $WTBD4004
〃 〃 〃 1.0 〃 500A Co2 DCφ1.0 (Low#) $WTBD4006
〃 〃 〃 1.2 〃 500A Co2 DCφ1.2 (Low#) $WTBD4007
〃 MAG 〃 0.8 〃 500A Mag DCφ0.8 (Low#) $WTBD4008
〃 〃 〃 1.0 〃 500A Mag DCφ1.0 (Low#) $WTBD4010
〃 〃 〃 1.2 〃 500A Mag DCφ1.2 (Low#) $WTBD4011
〃 MIG※4 SUS 0.8 〃 500A Mig_4 DCφ0.8 SuS (Low#) $WTBD4012
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 SuS (Low#) $WTBD4014
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 SuS (Low#) $WTBD4015
〃 〃 Ferrite 0.8 〃 500A Mig_4 DCφ0.8 Ferrite (Low#) $WTBD4016
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 Ferrite (Low#) $WTBD4018
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 Ferrite (Low#) $WTBD4019
DC
pulse
MAG
Mild Steel
Solid
0.8 〃 500A Mag DC-Pulseφ0.8 (Low) $WTBD4020
〃 〃 〃 1.0 〃 500A Mag DC-Pulseφ1.0 (Low) $WTBD4022
〃 〃 〃 1.2 〃 500A Mag DC-Pulseφ1.2 (Low) $WTBD4023
〃 〃 〃 1.6 〃 500A Mag DC-Pulseφ1.6 (Low) $WTBD4025
〃 MIG※4 SUS 0.8 〃 500A Mig_4 DC-Pulseφ0.8 SuS (Low) $WTBD4026
〃 〃 〃 1.0 〃 500A Mig_4 DC-Pulseφ1.0 SuS (Low) $WTBD4028
〃 〃 〃 1.2 〃 500A Mig_4 DC-Pulseφ1.2 SuS (Low) $WTBD4029
〃 〃 〃 1.6 〃 500A Mig_4 DC-Pulseφ1.6 SuS (Low) $WTBD4030
〃 〃 Ferrite 0.8 〃 500A Mig_4 DC-Pulseφ0.8 Ferrite (Low) $WTBD4031
〃 〃 〃 1.0 〃 500A Mig_4 DC-Pulseφ1.0 Ferrite (Low) $WTBD4033
〃 〃 〃 1.2 〃 500A Mig_4 DC-Pulseφ1.2 Ferrite (Low) $WTBD4034
〃 MIG※3 Hard Alm 1.0 〃 500A Mig_3 DC-Pulseφ1.0 Hard Al (Low) $WTBD4035
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulseφ1.2 Hard Al (Low) $WTBD4036
〃 〃 〃 1.6 〃 500A Mig_3 DC-Pulseφ1.6 Hard Al (Low) $WTBD4037
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC-Pulseφ1.2 Soft Al (Low) $WTBD4038
〃 〃 〃 1.6 〃 500A Mig_3 DC-Pulseφ1.6 Soft Al (Low) $WTBD4039
DC CO2
Mild Steel
Solid
0.8
Extended
cable
500A Co2 DCφ0.8 (Low*) $WTBD4040
〃 〃 〃 1.0 〃 500A Co2 DCφ1.0 (Low*) $WTBD4042
〃 〃
〃 1.2 〃 500A Co2 DCφ1.2 (Low*) $WTBD4043
〃 〃 〃 1.6 〃 500A Co2 DCφ1.6 (Low*) $WTBD4045
〃 〃
Mild Steel
Cored
1.2 〃 500A Co2 DCφ1.2 (Cored) (Low*) $WTBD4047
〃 〃 〃 1.6 〃 500A Co2 DCφ1.6 (Cored) (Low*) $WTBD4049
〃 〃 SUS Cored 1.2 〃 500A Co2 DCφ1.2 SuS(Cored) (Low*) $WTBD4051
〃 〃 〃 1.6 〃 500A Co2 DCφ1.6 SuS(Cored) (Low*) $WTBD4052
〃 MAG
Mild Steel
Solid
0.8 〃 500A Mag DCφ0.8 (Low*) $WTBD4053
〃 〃 〃 1.0 〃 500A Mag DCφ1.0 (Low*) $WTBD4055
〃 〃 〃 1.2 〃 500A Mag DCφ1.2 (Low*) $WTBD4056
〃 〃 〃 1.6 〃 500A Mag DCφ1.6 (Low*) $WTBD4058
〃 MIG※4 SUS 0.8 〃 500A Mig_4 DCφ0.8 SuS (Low*) $WTBD4059
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 SuS (Low*) $WTBD4061
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 SuS (Low*) $WTBD4062
〃 〃 〃 1.6 〃 500A Mig_4 DCφ1.6 SuS (Low*) $WTBD4063
〃 〃 Ferrite 0.8 〃 500A Mig_4 DCφ0.8 Ferrite (Low*) $WTBD4064
〃 〃 〃 1.0 〃 500A Mig_4 DCφ1.0 Ferrite (Low*) $WTBD4066
〃 〃 〃 1.2 〃 500A Mig_4 DCφ1.2 Ferrite (Low*) $WTBD4067
