Daihen OTC Almega AX Series User Manual

1.4 Welding mode lists
1-80
Welding process
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Notes
Number of welding
File comment
characteristic data in
AX21/FD11
ACWP 〃 〃 1.2 〃 350A
Mig_4 AC-Wave φ1.2 Ferrite (High) $WBTD6135
DCP 〃 〃 0.9 〃 350A Mig_4 DC-Pulse φ0.9 Ferrite (High) $WBTD6137
DCP 〃 〃 1.0 〃 350A Mig_4 DC-Pulse φ1.0 Ferrite (High) $WBTD6138
DCP 〃 〃 1.2 〃 350A Mig_4 DC-Pulse φ1.2 Ferrite (High) $WBTD6139
DCWP 〃 〃 0.9 〃 350A Mig_4 DC-Wave φ0.9 Ferrite (High) $WBTD6141
DCWP 〃 〃 1.0 〃 350A Mig_4 DC-Wave φ1.0 Ferrite (High) $WBTD6142
DCWP 〃 〃 1.2 〃 350A Mig_4 DC-Wave φ1.2 Ferrite (High) $WBTD6143
ACP 〃 〃 0.9 Standard 350A Mig_4 AC-Pulse φ0.9 Ferrite (Low) $WBTD6145
ACP 〃 〃 1.0 〃 350A Mig_4 AC-Pulse φ1.0 Ferrite (Low) $WBTD6146
ACP 〃 〃 1.2 〃 350A Mig_4 AC-Pulse φ1.2 Ferrite (Low) $WBTD6147
ACWP MIG※4 Ferrite 0.9 Standard 350A Mig_4 AC-Wave φ0.9 Ferrite (Low) $WBTD6149
ACWP 〃 〃 1.0 〃 350A Mig_4 AC-Wave φ1.0 Ferrite (Low) $WBTD6150
ACWP 〃 〃 1.2 〃 350A Mig_4 AC-Wave φ1.2 Ferrite (Low) $WBTD6151
DCP 〃 〃 0.9 〃 350A Mig_4 DC-Pulse φ0.9 Ferrite (Low) $WBTD6153
DCP 〃 〃 1.0 〃 350A Mig_4 DC-Pulse φ1.0 Ferrite (Low) $WBTD6154
DCP 〃 〃 1.2 〃 350A Mig_4 DC-Pulse φ1.2 Ferrite (Low) $WBTD6155
DCWP 〃 〃 0.9 〃 350A Mig_4 DC-Wave φ0.9 Ferrite (Low) $WBTD6157
DCWP 〃 〃 1.0 〃 350A Mig_4 DC-Wave φ1.0 Ferrite (Low) $WBTD6158
DCWP 〃 〃 1.2 〃 350A Mig_4 DC-Wave φ1.2 Ferrite (Low) $WBTD6159
ACWP AC wave pulse ※1 100%Ar
ACP AC pulse ※2 80%Ar, 20% CO
2
DCWP DC wave pulse ※3 97.5%Ar, 2.5%CO
2
DCP DC pulse ※4 98%Ar, 2%O
2
POINT
Normally, use the welding characteristic data given in Table 1.4.21 dedicated to “High”
application. The ones for “Standard” application must be used only when the welding
speed is low (50cm/min or lower in general), which causes unstable welding
performance.
