X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 57
CORACQ_PRM_LINE_TRIGGER_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_LINE_TRIGGER_DELAY min = 0 µs
max = 65535 µs
step = 1 µs
CORACQ_PRM_LINE_TRIGGER_DURATION min = 0 µs
max = 65535 µs
step = 1 µs
CORACQ_PRM_TAPS min = 1 tap
max = 16 tap
step = 1 tap
CORACQ_PRM_TAP_OUTPUT CORACQ_VAL_TAP_OUTPUT_ALTERNATE (0x1)
CORACQ_VAL_TAP_OUTPUT_SEGMENTED (0x2)
CORACQ_VAL_TAP_OUTPUT_PARALLEL (0x4)
CORACQ_PRM_TAP_1_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_2_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_3_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_4_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_5_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_6_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
