58 • X64 Xcelera-CL PX4 Reference X64 Xcelera-CL PX4 User's Manual
CORACQ_PRM_TAP_7_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_8_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_PIXEL_CLK_DETECTION CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_PRM_CHANNELS_ORDER CORACQ_VAL_CHANNELS_ORDER_NORMAL (0x1)
CORACQ_VAL_CHANNELS_ORDER_REVERSE (0x2)
CORACQ_PRM_LINESCAN_DIRECTION Not available
CORACQ_PRM_LINESCAN_DIRECTION_POLARITY Not available
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MIN 1 Hz
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MAX 16777215 Hz
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MIN 1 µs
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MAX 65535000 µs
CORACQ_PRM_CONNECTOR_HD_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_VD_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_RESET_TRIGGER_INPUT (*) Default = 0
CORACQ_PRM_TIME_INTEGRATE_PULSE1_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_TIME_INTEGRATE_PULSE1_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_PULSE1_DURATION min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_IO_CONTROL (*) ?
CORACQ_PRM_CONNECTOR_EXPOSURE_INPUT (*) Default = 0
CORACQ_PRM_TIME_INTEGRATE_PULSE0_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_TIME_INTEGRATE_PULSE0_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_PULSE0_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE1_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_LINE_INTEGRATE_PULSE1_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE1_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
