X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 59
CORACQ_PRM_LINE_INTEGRATE_PULSE0_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_LINE_INTEGRATE_PULSE0_DELAY min = 0 µs
max = 65535 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE0_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_VIDEO_LEVEL_MIN Default = 0 µV
CORACQ_PRM_VIDEO_LEVEL_MAX Default = 0 µV
CORACQ_PRM_CONNECTOR_LINE_TRIGGER_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_LINE_INTEGRATE_INPUT (*) Connector #1, type 2, pin #1
CORACQ_PRM_CONNECTOR_LINESCAN_DIRECTION_INPUT (*) Default = 0
CORACQ_PRM_CAMLINK_CONFIGURATION CORACQ_VAL_CAMLINK_CONFIGURATION_BASE (0x1)
CORACQ_PRM_DATA_VALID_ENABLE TRUE
FALSE
CORACQ_PRM_DATA_VALID_POLARITY CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_CONNECTOR_PIXEL_CLK_OUTPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_WEN_OUTPUT (*) Default = 0
CORACQ_PRM_WEN_POLARITY Not available
CORACQ_PRM_TAP_9_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_10_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_11_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_12_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
CORACQ_PRM_TAP_13_DIRECTION CORACQ_VAL_TAP_DIRECTION_LR (0x1)
CORACQ_VAL_TAP_DIRECTION_RL (0x2)
CORACQ_VAL_TAP_DIRECTION_UD (0x4)
CORACQ_VAL_TAP_DIRECTION_DU (0x8)
CORACQ_VAL_TAP_DIRECTION_FROM_TOP (0x10)
CORACQ_VAL_TAP_DIRECTION_FROM_MID (0x20)
CORACQ_VAL_TAP_DIRECTION_FROM_BOT (0x40)
