X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 71
CORACQ_PRM_DECIMATE_METHOD CORACQ_VAL_DECIMATE_DISABLE (0x1)
CORACQ_PRM_DECIMATE_COUNT Default = 0
CORACQ_PRM_LUT_ENABLE TRUE
FALSE
CORACQ_PRM_LUT_NUMBER Default = 0
CORACQ_PRM_STROBE_ENABLE TRUE
FALSE
CORACQ_PRM_STROBE_METHOD CORACQ_VAL_STROBE_METHOD_1 (0x1)
CORACQ_VAL_STROBE_METHOD_2 (0x2)
CORACQ_VAL_STROBE_METHOD_3 (0x4)
CORACQ_VAL_STROBE_METHOD_4 (0x8)
CORACQ_PRM_STROBE_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_STROBE_DURATION min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_STROBE_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_FRAME_INTEGRATE_ENABLE Not available
CORACQ_PRM_FRAME_INTEGRATE_COUNT Not available
CORACQ_PRM_TIME_INTEGRATE_ENABLE TRUE
FALSE
CORACQ_PRM_TIME_INTEGRATE_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_CAM_RESET_ENABLE TRUE
FALSE
CORACQ_PRM_OUTPUT_FORMAT CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_VAL_OUTPUT_FORMAT_RGB16161616
CORACQ_PRM_EXT_TRIGGER_ENABLE CORACQ_VAL_EXT_TRIGGER_OFF (0x1)
CORACQ_VAL_EXT_TRIGGER_ON (0x8)
CORACQ_PRM_VIC_NAME Default Area Scan
CORACQ_PRM_LUT_MAX 1
CORACQ_PRM_EXT_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_DC_REST_START min = 0 pixel
max = 0 pixel
step = 1 pixel
CORACQ_PRM_DC_REST_WIDTH min = 0 pixel
max = 0 pixel
step = 1 pixel
CORACQ_PRM_LUT_FORMAT Default = CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_PRM_VSYNC_TIMEOUT Not available
CORACQ_PRM_VSYNC_REF CORACQ_VAL_SYNC_REF_END (0x2)
CORACQ_PRM_HSYNC_REF CORACQ_VAL_SYNC_REF_END (0x2)
