72 • X64 Xcelera-CL PX4 Reference X64 Xcelera-CL PX4 User's Manual
CORACQ_PRM_LINE_INTEGRATE_ENABLE TRUE
FALSE
CORACQ_PRM_LINE_INTEGRATE_DURATION min = 1 pixel
max = 16777215 pixel
step = 1 pixel
CORACQ_PRM_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_VAL_DOUBLE_PULSE_RISING_EDGE (0x20)
CORACQ_VAL_DOUBLE_PULSE_FALLING_EDGE (0x40)
CORACQ_PRM_EXT_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_LINE_TRIGGER_DETECTION CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_PRM_SNAP_COUNT Default = 1 frame
CORACQ_PRM_INT_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_INT_LINE_TRIGGER_FREQ Default = 5000 Hz
CORACQ_PRM_LINESCAN_DIRECTION_OUTPUT (*) Not available
CORACQ_PRM_BIT_ORDERING CORACQ_VAL_BIT_ORDERING_STD (0x1)
CORACQ_PRM_EXT_TRIGGER_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_STROBE_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_PRM_EXT_FRAME_TRIGGER_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_EXT_LINE_TRIGGER_LEVEL CORACQ_VAL_LEVEL_422 (0x2
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MIN 245 Hz
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MAX 500000 Hz
CORACQ_PRM_MASTER_MODE Not available
CORACQ_PRM_MASTER_MODE_HSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_MASTER_MODE_VSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_SHAFT_ENCODER_DROP min = 0 tick
max = 511 tick
step = 1 tick
CORACQ_PRM_SHAFT_ENCODER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_TRIGGER_FRAME_COUNT Default = 1 frame
CORACQ_PRM_INT_FRAME_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_INT_FRAME_TRIGGER_FREQ min = 1 milli-Hz
max = 1073741823 milli-Hz
step = 1 milli-Hz
CORACQ_PRM_SHARED_EXT_TRIGGER Not available
CORACQ_PRM_SHARED_CAM_RESET Not available
CORACQ_PRM_SHARED_CAM_TRIGGER Not available
CORACQ_PRM_SHARED_TIME_INTEGRATE Not available
