Figure 4-93 Terminal Block Fuse Removal
4.13.2.2 Terminal Block Fuse Installation
1. PlacethefuseontheTerminalBlockandoverthethreadsontheshortbusbar.
2. Installthe5/16-18nutontheloadsideofthefuseandtorqueto20Nm(15ft.lb.).
3. Installthe5/16-18fasteneronthelinesideofthefuseandtorqueto20Nm(15ft.lb.).
4. Installthetopcovers.RefertoSection4.1CompressorCoversonpage52.
5. Returnthecompressortonormaloperation.
Table 4-21 Terminal Block Fuse Torque Specifications
Description Nm Ft.Lb. In.Lb.
TTS300/TGS230FuseRetainingfastener,5/16-18 20 15 177
TTS300/TGS230FuseRetainingnut,5/16-18 20 15 177
CoverFastener,M5x15 1.5 - 13

Page 112 of 294 - M-SV-001-EN Rev. H 1/23/2023
