J8 – External sensor inputs
l
SpareT:Externaltemperaturesensorinput

o
RefertotheApplicationsandInstallationManualforthermistorspecifications
l
SpareP:Externalpressuresensorinput

o
RefertotheApplicationsandInstallationManualforpressuresensorspecifications

o
RefertotheOEMProgrammingManualforsoftwareimplications
D1 to D8 – EXV LED indicators
l
Red:2setsof4LEDsforEXV1&EXV2
D9 – Power LED
l
Green:ON:compressorison(i.e.,CompressorI/OBoardandBMCCareproperlyconnectedtothe
Backplane)
4.3.2 Compressor Interface Module Verification

4.3.2.1 Determining if the Compressor Interface Module is Draining Energy
1. IdentifyiftheD9,greenlight-emittingdiode(LED)ison.
2. RemovetheServiceSideCover.RefertoSection4.1.3.1ServiceSideCoverRemovalandInstallationon
page54.
3. MeasuretheBackplane+5Vand+15Vtestpointvoltages.
4. RemoveallexternalconnectionstotheI/Oboard.
5. MeasuretheBackplane+5Vand+15Vtestpointvoltages.
6. IsolatecompressorpowerandwaitfortheBackplaneLEDstoturnoff.
7. DisconnectthecompressorInterfacecablefromtheJ6connectorontheCIM.
8. Applypowertothecompressor.
9. MeasuretheBackplane+5Vand+15Vtestpointvoltages.
10. Ifvoltagesdonotchange,I/Oboardisnotdrainingenergy.
4.3.2.2 Compressor Interface Module Communication Verification
1. ConnecttheCIMtoacomputer.
2. Confirmserialporttobeusedbythecomputer.
3. OpentheServiceMonitorTool(SMT)softwareandselectthe Compressor Connection Managertool.
SeetheServiceMonitoringToolsUserManualforuseinstructions.
4. ClickConnect.
l
IftheCompressorConnectionManagerisabletoconnecttothecompressor,theBMCCisableto
communicatewiththeuserinterface.
l
Ifthesystemisnotabletoconnect,verify:

o
TheD9,greenLEDison

o
ThecableconnectionbetweentheBackplane(portJ7)andtheCIM(portJ6)isproperly
attached

o
ThecableconnectionbetweentheCIM(atportJ1ifusingRS485communicationoratportJ7
ifusingRS232communication)andtheuser’scomputerisproperlyattached

o
TheBMCCisproperlyconnectedtotheBackplane
5. IfallconnectionsareproperlyattachedandyoustillcannotconnecttothecompressorwiththeSMT,
confirmcomputerserialport,thenusetheSearchfunctionintheCompressorConnectionManagerto
determinethecorrectbaudrateandslaveaddressofthecompressor.RefertotheServiceMonitoring
Page 62 of 294 - M-SV-001-EN Rev. H 1/23/2023
