Danfoss TTS400


11. InstallthebeveledwashersandsolenoidretainingnutstosecuretheSolenoidActuatorCoils.

• • • CAUTION • • •
Onlyhandtightenthesolenoidretainingnuts.Donotover-tightenoruseplierstoinstall.

12. ReconnecttheSolenoidCoilstoJ16ontheBackplane.
13. InstalltheServiceSideCover.RefertoSection4.1CompressorCoversonpage52.
14. Returnthecompressortonormaloperation.
4.6.4.3 Solenoid Torque Specifications
Table 4-11 Solenoid Torque Specifications
Description Nm Ft.Lb. In.Lb.
SolenoidTube/Plunger 4 - 35
OrificeValve 7 - 62
CoverFastener,M515 1.5 - 13


M-SV-001-EN Rev. H-1/23/2023 Page 77 of 294
