NOTE
TheTTS300/TGS230seriescompressorsdonotutilizecablelugs.Becauseofthis,torquespecificationswillvarydependingonthetypeof
cabling.Itisrecommendedtocontactthemanufacturerofthecablingusedfortheappropriatetorquespecification.
7. Installthetopcovers.RefertoSection4.1CompressorCoversonpage52.
8. Returnthecompressortonormaloperation.
4.10.1.3 Mains Plate Torque Specifications
Table 4-17 Mains Plate Torque Specifications
Description Nm Ft.Lb. In.Lb.
MainsPlateMountingScrew,M6x16 7 - 62
CoverFastener,M5x15 1.5 - 13
UpperNut,5/16"-18UNC 10 7 89
JamNut,5/16"-18UNC 7 - 62
LowerNut,5/16"-18UNC 20 15 177
MainsInputNut,3/8"-16UNC(excludesTT300/TG230compressors) 21 15 186
MainsInputPressureScrew,11/16"-16UNC(TTS300/TGS230compressorsonly) 20 15 177


Page 98 of 294 - M-SV-001-EN Rev. H 1/23/2023
