Danfoss TTS400 User Manual

Description Nm Ft.Lb. In.Lb.
TerminalBlockfastener,M5x15(TTS300/TGS230only) 3 - 27
DCBusBarstoSCRfastener,M6x16(TTS300/TGS230
only)
5 - 44
SCRCoolingManifoldtoInverterCoolingManifold
fastener,M6x20(TTS300/TGS230only)
7 - 62
SCRCoolingManifoldtoInverterCoolingManifold
fastener,M6x35(ExcludesTTS300/TGS23compressors)
8.5 - 75
ACBusBartoSCRfastener,M8x20(Excludes
TTS300/TGS230compressors)
9 - 80
TerminalBlockMountingfastener,M5x45(Excludes
TTS300/TGS230compressors)
4 - 35
DCBustoSCRfastener,M8x20(TTS300/TGS230only) 9 - 80
CapacitorDCBusBartoSCRfastener,M8x20(excludes
TTS300/TGS230compressors)
9 - 80
MainsInputPressureScrew,11/16"-16UNC
(TTS300/TGS230compressorsonly)
20 15 177
MainsInputNut,3/8"-16UNC(excludes
TTS300/TGS230compressors)
21 15 186
SnubberCapacitorfastener,M6x16 7 - 62
NylonCapacitorNut 7 - 62
SoftStartMountingfastener,M5X15 5 - 44
InvertertoMotorBusBarfastener,M8x70 14 10 124
InverterAssemblyMountingfastener,M6x30 8.5 - 75
DC-DCMountingfastener,M3x10 0.6 - 5
BackplaneGroundfastener,M5x10 3 - 27
IGVFeedthroughRetainerClipfastener,M5x16 25 18 221
GroundPostTopNut,5/16"-18UNC 7 - 62
GroundPostSecond(Jam)Nut,5/16"-18UNC 7 - 62
CoverFastener,M5x15 1.5 - 13
CoverFastener,M5x20(#3onCapacitorCover) 1.5 - 13

M-SV-001-EN Rev. H-1/23/2023 Page 193 of 294
