Illustration 3.74 MCT 10 Set-up Software
The LCP indicates (with a wrench icon and letter M) when it is time for a preventive maintenance action and can be
programmed to be indicated on a digital output in parameter group 5-3* Digital Outputs. The preventive maintenance status
is shown in parameter 16-96 Maintenance Word. A preventive maintenance indication can be reset from a digital input, the
FC bus, or manually from the LCP through parameter 23-15 Reset Maintenance Word.
A maintenance log with the latest 10 loggings can be read from parameter group 18-0* Maintenance Log and via [Alarm Log]
on the LCP after selecting maintenance log.
NOTICE
The preventive maintenance events are dened in a 20-element array. Hence, each preventive maintenance event must
use the same array element index in parameter 23-10 Maintenance Item to parameter 23-14 Maintenance Date and Time.
23-10 Maintenance Item
Array [20]
Option: Function:
Array with 20 elements shown below
the parameter number in the display.
Press [OK] and step between
elements with [◄], [►], [
▲
], and [
▼
].
Select the item to be associated with
the preventive maintenance event.
[1] * Motor bearings
[2] Fan bearings
[3] Pump bearings
[4] Valve
[5] Pressure transmitter
[6] Flow transmitter
[7] Temperature transm.
23-10 Maintenance Item
Array [20]
Option: Function:
[8] Pump seals
[9] Fan belt
[10] Filter
[11] Drive cooling fan
[12] System health check
[13] Warranty
[20] Maintenance Text 0
[21] Maintenance Text 1
[22] Maintenance Text 2
[23] Maintenance Text 3
[24] Maintenance Text 4
[25] Maintenance Text 5
[26] Service log full
