Datalogic Magellan 800i User Manual

Getting Started
4 Magellan
TM
800i
LED and Beeper Indicators
The scanner’s beeper sounds and its green LED illuminates to indicate various functions
or errors on the scanner. The tables below list these indications. One exception to the
behaviors listed in the tables is that the scanner’s functions are programmable, and may
or may not be turned on. For example, certain indications, such as the power-up beep
can be disabled using programming bar code labels.
Green LED Indications
LED
INDICATION
INDICATION COMMENT
Power-on
indication
Bright green flash
Indicates the scanner has finished all its power up tests and is
now ready for operation.
Good Read
Indication
Bright green flash Indicates a bar code has been read and decoded.
Scanner Ready Constant dim green The scanner is ready for operation.
Sleep Mode
Constant green flash
(100mS on, 1900mS off)
The scanner is in Sleep Mode. To wake the scanner up, move
an object in front of its window.
Host Disable
Constant green flash at 1 Hz
(100mS on, 900mS off)
The scanner is disabled due to receiving a disble command
from the POS terminal.
Diagnostics
Varies (see
Error Codes on
page 5 for more information)
The LED can provide diagnostic feedback if the scanner dis-
covers a problem during SelfTest.
Prog. Mode See
Host Disable above. The scanner is in Programming Mode.
BEEPER FUNCTIONS
BEEPER
INDICATION
INDICATION COMMENT
Power On Beep Single beep
The Power-On LED indication is a configurable feature which
can be enabled or disabled. When enabled, this beep Indi-
cates the scanner has finished all its power up tests and is
now ready for operation.
Good Read
Indication
Single beep
The good read beep indication is configurable. Options
include: Enable/disable, frequency, duration and volume. See
the
“LED and Beeper Indicators” section on page 12 for more
information.
Diagnostics
Varies (see
Error Codes on page 5
for more information)
The Beeper can provide diagnostic feedback if the scanner
discovers a problem during SelfTest.
Programming
Mode
Indications
Varies depending upon the fea-
ture(s) being configured.
The Beeper will sound as programming bar code labels are
scanned, indicating progress during scanner configuration.

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
