Datalogic Magellan 800i User Manual

164 Magellan
TM
800i
Interface Default Exceptions
The factory default settings indicated in the programming sections (in bold text) reflect factory configuration for
the RS-232 standard interface. The following tables list default exceptions by interface for the remaining available
interfaces.
RS-232 Wincor/Nixdorf
USB Keyboards
Parameter Default Setting
Interface Type RS-232-WN
Number of Host Transmit Buffers One Buffer
RS-232 Parity Odd
RS-232 Hardware Control CTS Flow Control
UCC/EAN-128 Label ID ‘P’
Code 39 Label ID ‘M’
Code 93 Label ID ‘L’
Code 128 Label ID ‘K’
Codabar Label ID ‘N’
EAN-8 Label ID ‘B’
EAN-13 Label ID ‘A’
ISBN Label ID ‘A’
Interleaved 2 of 5 Label ID ‘I’
Standard 2 of 5 Label ID ‘H’
MSI/Plessey Label ID ‘O’
UPC-E Label ID ‘C’
GS1 DataBar Omnidirectional Label ID ‘E’
GS1 Expanded Label ID ‘E’
Parameter Default Setting
Label ID Transmission Disable

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
