MATRIX 300N™ REFERENCE MANUAL
152
9
TROUBLESHOOTING GUIDE
Problem
Suggestion
Communication:
data transferred to the host
are incorrect, corrupted or
incomplete.
Are the host serial port settings the same as the reader
serial port settings?
In the DL.CODEData Formatting step check the
settings of Header and Terminator String parameters.
In the DL.CODEData Formatting step, check the
various Message Field parameter settings.
Configuration:
cannot access environment
parameters in DL.CODE
(Device>Settings>Settings
menu item is grey)
Are you using the Installer - Expert User level? If not
change it in the Options>Change User menu.
How do I obtain my reader
Serial Number?
The reader Serial Number consists of 9 characters: one
letter, 2 numbers, another letter followed by 5 numbers.
The reader Serial Number is printed on a label that is
affixed on the bottom case near the reading window.
The Serial Number is also visible from the DL.CODE
Device List Area.
How do I obtain my reader
Order Number?
The reader Order Number consists of 9 numbers.
The reader Order Number can be obtained by
comparing the Device Model (in DL.CODE Device
Menu > Settings > Settings > About Device) with the
product models page on the Datalogic website.
