Datamax I-Class - Alignment Procedure; Avoiding Specular Reflection

Overview
1-2
1.1 About the Printer
The following drawing highlights the user-assessable components of the printer.
Access Cover
Printhead
Media Sensor
Ribbon Supply Hub
Ribbon Take-Up Hub
Front Panel
Printhead Assembly
Fill Block
Media Hub
Internal Rewinder
Printhead Latch
Leveling Cam
Media Idler
Ribbon Idler
Media Guide
Platen
