Datamax I-Class Maintenance Manual

Removal and Replacement
4-2
3. Remove the two Screws that secure the Cover Assembly to the Baseplate, and then lift the Cover
Assembly off the printer.
Screws
Baseplate
Replacement:
1. Lower the Cover Assembly onto the printer.
2. Reinstall the two Screws through the Cover Assembly and into the Baseplate.
3. Tighten the two Screws along the Baseplate and the two Screws along the Centerplate.
4.2 Front Panel
Removal:
1. Turn OFF and unplug the printer.
2. Remove the Cover Assembly (see Section 4.1) and the Fascia (see Section 4.3).

Datamax I-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi, or 600 dpi
Max Print Speed	10 inches per second (254 mm/s)
Interface	USB, Serial, Parallel
Media Types	Paper, Polyester, Polypropylene, Vinyl, Nylon
