V0215, 5.3
found in this menu.
+Save
Save a bendsequence will save the resulting CNC program on disk. The resulting CNC
program contains all necessary axis positions and tool numbers. This command can only be
executed when a complete bend sequence has been determined.
+Save as
Save as can be used to save the current product and its bendsequence under an alternative
name. This enables an easy way to make product differentiations (variants).
When the bendsequence screen is left, the product will automatically be saved. If there are
changes made, and save is not used, this will be prompted on the screen.
Show Bendsequence
To show a mosaic screen with a step-by-step graphical overview of the bend sequence.
5.1.1. Bend selector
Within the bendsequence screen bends can be selected and navigated thru with the bend
selector. In the top of the screen the number of bends is indicated with preliminary bend
selectors. After completing the bend sequence, these are all colored, active and show a turn
indicator.
From then bends can be tapped to easily to select the desired bend data. In the bend selector
the turn indicator will be displayed showing green, yellow or red colors to indicate the level of
complying the assignments of the bend sequence.
