7.2.6. Corrections
In this view mode all corrections of all bends are shown. You can browse through all
corrections and change them as you see fit. If a correction for
α1 is entered then this value is
copied to the correction for
α2. Different corrections for α2 can be entered in the field itself.
The column 'Stored correction' is only available when the Angle correction database has been
activated. When activated, the column 'Stored correction' shows for each bend the correction
value that is present in the database. A blank entry in this column means the database does
not have a correction value for this type of bend. When a new correction is entered, it will be
copied to the database automatically.
The markers '>' indicate bends that have the same value.
All From Stored serves to copy corrections in the database to the current program: corrections
in all bends are adjusted according to database values.
Bend Allowance
The function Bend Allowance helps the user to add entries to the bend allowance table in case
this is active. Based on the active bend parameters only the bend allowance corrections need
to be entered before adding. When the measured value is given, this will result in a calculated
bend allowance, derived from the difference between the programmed value and the
measured value. To enable the bend allowance table go to the Settings mode.
