V0215, 6.10
With Accept you leave the window and the new values have been saved. If you press Cancel
you leave the window without changes.
When you have changed Lay-on then the axes positions in X- and R-direction have been
changed. The new values depend on the dimensions of the back gauge finger which you have
programmed in the Machine mode. When you have changed the values of R and X, then
these changes are also included.
Lay-on = 0
Lay-on = 1
