Table 3. Features available on the front of the system (continued)
Item Ports, panels, and slots Icon Description
5 USB 2.0 port
The USB ports are 4-pin, 2.0-compliant. These ports enable you to
connect USB devices to the system.
6 USB 3.0 port
The USB ports are 9-pin and 3.0-compliant. These ports enable you to
connect USB devices to the system.
7 NVMe drives N/A Enables you to install NVMe drives that are supported on your system.
8 BOSS S2 module (optional) N/A This slot supports the BOSS S2 module.
9 Drive N/A Enables you to install SAS/SATA drives that are supported on your
system.
Figure 4. Front view of 8 x 3.5-inch drive system
Table 4. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 Power button
Indicates if the system is powered on or off. Press the power button to
manually power on or off the system.
14 PowerEdge T550 system overview
