Dell E76S - Installing the Front Bezel

Figure 25. Removing the front bezel
Next steps
Replacing the front bezel.
Installing the front bezel
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Locate and remove the bezel key.
NOTE: The bezel key is part of the LCD bezel package.
Steps
1. Insert the bezel tabs into the slots on the system.
2. Push the bezel toward the system until the bezel locks into place.
3. Lock the bezel.
Installing and removing system components
37
