Dell E76S - Installing a AC Power Supply Unit

Figure 170. Removing a 86 mm power supply unit
Next steps
Install the PSU.
Installing a AC power supply unit
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. For systems that support redundant PSU, ensure that both the PSUs are of the same type and have the same maximum
output power.
NOTE: The maximum output power (shown in watts) is listed on the PSU label.
Steps
Slide the PSU into the system until the PSU is fully seated and the release latch snaps into place.
Figure 171. Installing a 60 mm power supply unit
