Figure 51. Installing a drive into the drive carrier
Removing a 3.5-inch drive adapter from a 3.5-inch drive carrier
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. If installed, remove the front bezel.
3. Remove the drive carrier.
Steps
1. Using a Phillips 1 screwdriver, remove the screws from the rails on the drive carrier.
NOTE:
If the drive carrier has Torx screw, use Torx 6 (for 2.5-inch drive) or Torx 8 (for 3.5-inch drive) screwdriver to
remove the drive.
2. Lift the 3.5-inch drive adapter out of the 3.5-inch drive carrier.
60
Installing and removing system components
