Dell E76S - Page 171

Table 44. System board jumpers and connectors
Item Connector Description
1. FAN_SIG1 Fan Signal 1
2. FAN_SIG2 Fan Signal 2
3. PIB_SIG1 PIB Signal 1
4. PIB_SIG2 PIB Signal 2
5. INTRUSION Intrusion Switch Connector
6. SYS_PWR1 System Power Connector 1
7. SIG_PWR_0 Power connector for cable riser
8. Coin cell battery Coin cell battery
9. SL6_CPU2_PB3 PCIe cable connector 6 (Processor 2)
10. X16 (CPU2) x16 PCIe slot 6 ( Processor 2)
11. SYS_ID System ID Connector
12. SL5_CPU2_PA3 PCIe cable connector 5 (Processor 2)
13. x16 (CPU2) PCIe slot 5 ( Processor 2)
14. OCP 3.0 x16 OCP NIC 3.0 Connector
15. J_TPM TPM Connector
16. SL7_CPU1_PA4 PCIe cable connector 7 (Processor 1)
17. IDSDM/Internal USB connector IDSDM/Internal USB connector
18. REAR_SERIAL Serial Port Connector
19. x4 (PCH) x4 PCIe slot 2 (PCH)
20. SL8_CPU1_PB4 PCIe cable connector 8 (Processor 1)
21. FRONT_USB Front USB
22. SL10_PCH_PA5 BOSS signal connector (PCH)
23. FRONT_VIDEO Front VGA
24. x16 (CPU1) x16 PCIe slot 1 (Processor 1)
25. SL9_PCH_SA1 SATA Connector S9 (PCH)
26. ODD Optical disk drive connector
27. RGT_CP Right Control Panel
28. A3, A7, A1, A5 DIMMs for processor 1 Channels A, B, C,
D
29. CPU 1 Processor 1
30. SL4_CPU1_PA2 PCIe cable connector 4 (Processor 1)
31. A6, A2, A8, A4 DIMMs for processor 1 Channels A, B, C,
D
32. SL3_CPU1_PB2 PCIe cable connector 3 (Processor 1)
33. B3, B7, B1, B5 DIMMs for processor 2 Channels E, F, G,
H
34. SYS_PWR2 System Power Connector 2
35. SL2_CPU2_PA1 PCIe cable connector 2 (Processor 2)
Jumpers and connectors 171
