Expansion Cards 111
12
If you removed a network adapter card:
a
Enter system setup, select
Network Controller
, and change the setting to
On
(see "Entering
System Setup" on page 280).
b
Connect the network cable to the integrated network connector on the back panel of the
computer.
Installing a PCI Card in the Riser-Card Cage
1
Follow the procedures in "Before You Begin" on page 21.
2
Remove the computer cover (see "Removing the Computer Cover" on page 90).
3
If applicable, remove the card installed in the PCI3 connector on the system board.
4
Remove the riser-card cage:
a
Check any cables connected to cards through the back panel openings. Disconnect any cables that
will not reach the riser-card cage once they are removed from the computer.
b
Gently pull on the handle and lift the riser-card cage up and away from the computer.
1 riser-card cage
2 handle
1
2
